British Style 36W EF86

  • 36 Watt

The Ceriatone 36W TMB EF86 is big brother to the 18W TMB EF86, and features the same channels in a firmer, louder, punchier power section.

The EF86 channel is known for it’s incredible clarity and balance across the fingerboard.  Because of the high headroom of the EF86 preamp tube, this channel responds particularly well to pedals.

The TMB channel features a preamp somewhat similar to a Plexi50 or Plexi100, but with special care in matching it’s voice to the unique EL84/GZ34 power section.  Some of our favorite rock tones of ANY of our amplifiers are in the TMB channel.  As an added bonus, we incorporated a master volume for this channel only.

Like our other modified 18Ws and 36Ws, this chassis is suitable for both head and combo formats.

Like other Ceriatone amps, we have labored carefully to select the finest components to suit the design, and the 36W uses our specially designed, custom transformers for superior reliability, frequency response, and feel.

Power Output 36 Watt
Feature Overview
  • Dual channel (EF86, TMB)
  • EF86 channel with dual inputs (high, low gain)
  • EF86 channel controls: Volume and Tone (6-way rotary switch)
  • “TMB” channel controls: Treble, Middle, Bass, and Master Volume
  • Tubes
  • Power: 4 x EL84
  • Preamp: 3 x 12AX7/ECC83, 1 x EF86
  • Rectifier: GZ34/5AR4
  • Head Complete Head Unit USD 1,025.00 23.0kg Full working chassis in head cabinet.
    Options Without tubes USD 900.00 23.0kg Full working chassis without tubes in head cabinet
    Without head cabinet USD 860.00 16.0kg Full working chassis without head cabinet
    Without head cabinet and tubes USD 735.00 16.0kg Full working chassis without tubes and head cabinet
    Combo Complete Combo 1x12 Unit USD 1,100.00 35.0kg Full working chassis in combo 1x12 cabinet, sans speaker. Email us to enquire on speaker choice.
    Complete Combo 2x12 Unit USD 1,135.00 57.0kg Full working chassis in combo 2x12 cabinet, sans speakers. Email us to enquire on speaker choice.
    British Style 36W EF86 Kits Package 1 USD 390.00 5.0kg All components with unassembled board, front plate, rear plate, and chassis. No OT, no PT, no tubes and no cabinet.
    Package 2 USD 565.00 16.0kg All components with unassembled board, front plate, rear plate, chassis, OT and PT. No tubes and no cabinet.
    Package 1 with assembly USD 560.00 7.0kg All components with assembled board, front plate, rear plate, and fully assembled in chassis. No OT, no PT, no tubes and no cabinet.
    Board Unassembled board USD 110.00 2.5kg
    Cabinet Head USD 165.00 21.0kg Weight is for empty head cabinet only
    Combo 1 x 12 cabinet USD 240.00 35.0kg Price and weight is for empty combo cabinet, without speaker. Email us to enquire on speaker choice.
    Combo 2 x 12 cabinet USD 275.00 57.0kg Price and weight is for empty combo cabinet, without speaker. Email us to enquire on speaker choice.
    Chassis Aluminum (Head/Combo) USD 75.00 4.0kg Laser Punched Alum, Thickness 2.0 mm
    Faceplate Front plate USD 28.00 1.5kg Plexi/Acrylic, Reversed Silk Screened
    Rear plate USD 28.00 1.5kg Plexi/Acrylic, Reversed Silk Screened
    Trannies Power & output trans USD 175.00 10.0kg
    Tubes 3 x 12AX7, 4 x EL84, 1 x GZ34 , 1 x EF86 USD 125.00 3.5kg
    Layout British Style 36 Watt EF86 Download
    Manual British Style 36 Watt EF86 Download
